Removing & Installing Body Components
Seat
Make sure the electrical system is turned off.
Do not store any items under the seat that are flammable or susceptible to heat damage.
Removal
Cancel the 12 V battery automatic charge mode.
Remove the seat rail covers by removing the bolts.
The left side and right side seat rail covers can be removed in the same way.
Remove the seat mounting bolts.
Pull the seat back and up.
Seat mounting bolts
Seat
Centre prongs
Tabs
Recess
Centre stay |
Installation
Insert the tabs into the recess.
Insert the centre prongs into the centre stay.
Install the seat mounting bolts, and tighten the mounting bolts securely.
|
Torque: 27 N·m (2.8 kgf·m, 20 lbf·ft) |
Install seat rail covers and bolts, and tighten the bolts securely.
|
